Ruijie Wifi 5 Wall Access Point

Product Specification

Overview

Ruijie RG-AP710 Wireless Access Point มาตรฐาน AC 2x2 MU-MIMO Dual-Band กระจาย 2 ย่านความถี่ ความเร็วสูงสุด 1.167Gps

1 Port Lan Gigabit รองรับ POE มาตรฐาน 802.3af

รองรับการทำ Authenticate แบบ Captive Portal, Social Login

Manage และ Monitor ผ่าน Cloud, Standalone และ Hardware Control

พร้อม Ruijie Cloud License แบบ Lifetime

Type

Wall-mounting

Radio

Concurrent dual-band dual-radio

Protocol

802.11a/b/g/n
802.11ac Wave 1
802.11ac Wave 2

Operating Bands

2.4GHz and 5GHz

Antenna

Built-in omnidirectional antenna
2x2 MU-MIMO

Max Throughput

1,167Mbps

Spatial Streams

2 x 2

Modulation

11b: DSS:CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps
11a/g: OFDM:64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps
11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM
11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM

Maximum Transmit Power

≤100mW (20dBm, transmit power of the RF card only)

IP Rating

IP41

Ports

Front:
4 10/100/1000M Ethernet ports
Side:
1 RJ-45 port  (RJ-11 combo)
Rear:
1 10/100/1000M uplink port
1 RJ-45 pass-through port (RJ-11 combo)

Management Port

1 console port (Micro USB)

Lock

Standard: Anti-theft screws and ordinary screws
Optional: Lock and key

Color Plate Cover Options

White, black, silver and gold

LED Indicators

1 LED status indicator

Maximum clients per AP

Up to 32

BSSID capacity

Up to 8 per radio
Up to 16 per AP

SSID hiding

Support

Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID

Support

Remote Intelligent Perception Technology (RIPT)

Support

Intelligent identification of smart device

Support

Intelligent load balancing based on the number of users or traffic

Support

STA control

SSID/radio-based

Bandwidth control

STA/SSID/AP-based speed control

PSK, Web, 802.1x authentication

Support

Data encryption

WPA (TKIP), WPA2 (AES), WPA-PSK, and WEP (64 or 128 bits)

QR code authentication

Support

SMS authentication

Support

PEAP authentication

Support

Data frame filtering

Whitelist, static/dynamic blacklist

User isolation

Support

Rogue AP detection and countermeasure

Support

Dynamic ACL assignment

Support

RADIUS

Support

CPU Protection Policy (CPP)

Support

Network Foundation Protection Policy (NFPP)

Support

Wireless Intrusion Detection System(WIDS)

Support

Wireless Intrusion Prevention System (WIPS)

Support

Remote probe

Support

IPv4 address

Static IP address or DHCP reservation

IPv6 address

Manual or automatic configuration

Multicast

Multicast to unicast conversion

Wireless position tracking

Support

Network management

SNMP v1/qav2C/v3, Telnet, TFTP, Web management

Visualized wireless heat map analysis

Support

Real-time spectrum analysis

Support

Fault detection and alarm

Support

Statistics and logs

Support

FAT/FIT switching

The AP working in FIT mode can switch to the FAT mode through the RG-WS wireless AC.
The AP working in FAT mode can switch to the FIT mode through a local console port or Telnet.

Safety Standard

GB4943
EN/IEC 60950-1

Dimensions (W x D x H) (mm)

116 × 86 × 42

Weight

0.23kg

Installation Mode

Standard 86-type faceplate installation

Power Supply

Not Include

PoE (802.3af), Local DC power supply

Power Consumption

<8W

Temperature

Operating Temperature:
-10°C to 45°C
Storage Temperature:
-40°C to 70°C

Humidity

Operating Humidity:
5% to 95% (non-condensing)
Storage Temperature:
5% to 95% (non-condensing)

ประกัน

3 ปี
